3-Phase Network Parameter Analyzer

3-Phase Network Analyzer / Network Analyzer / Network Parameter Meter - Multifunctional digital panel meter, current, voltage, frequency and total power indicator, with two relay outputs and digital input, RS485 ModBus RTU - TPM-01ESH manufacturer TENSE (Turkey)

The multifunctional power network analyzer is designed for accurate measurement of parameters of three-phase networks

Power analyzers are designed to measure and monitor electrical values. Using the communication function, energy measurements can be independently monitored and reported

Main advantages:

• RS485 Modbus RTU (1200-38400bps)
• 3-phase voltage transformer and 3-phase current transformer.

• Displays voltage and current harmonics up to the 31st harmonic

• Shows active power per phase (P)

• Shows reactive power per phase (Q, inductive and capacitive)

• Shows apparent powers in phase (S)

• Shows the Cosφ and power factor values of each phase

• Shows the phase-neutral, phase-to-phase voltage (V) and current (I) values of each phase, measuring frequency

• Displays total active energy import and export values (ΣkWh)

• Displays total inductive and capacitive reactive energy values (ΣkVArh)

• Displays minimum and maximum values, max. need

• 2 relay outputs, 1 digital input

• Event logs (high/low voltage/current, voltage/current imbalance, THD-I)

• Menu is password protected.

Usually this network analyzer is used with current measuring transformers - 60/5 75/5 100/5 150/5 200/5 250/5 300/5 400/5 500/5 600/5 800/5 1000/5 1500/5 or similar. You can buy such transformers in our e-shop, If you are going to connect the analyzer to ModBus, we will send you on request a Register Table with ModBus addresses
