3 Phase Under / Over Voltage Current Protector Smart Control Relay With Phase Fail / Sequence Control, DIN Rail Mount, up to 63A

SKU: GKE-63T

Price including VAT:

ÂŁ78.00
ÂŁ78.00
Out of stock
  • Description
  • Download
  • Payment methods
  • Warranty

The Tense GKE-63T is a 63A-rated, microprocessor-controlled digital 3-phase voltage and current protector.

Key Protections: High/low voltage, overload, phase unbalance, phase rotation/sequence faults, overheating, broken neutral protection, and ultra-fast short-circuit response (0.04s)


Operating Modes:
  • Synchronous Mode: Three-phase single-circuit protection. The monitoring relay protects the three-phase voltage with L1, L2, L3 and N configured as a single circuit.
  • Asynchronous Mode: Independent Phase-by-Phase Protection
    In this mode, the protection relay operates as three independent single-phase protectors. These can be connected to three separate circuits, allowing the monitoring relay to track and register trips, stops, and resets for each individual circuit.
Adjustment Ranges:
  • Current: 1–63A
  • Low Voltage: 80–210V
  • High Voltage: 220–300V
  • Voltage Asymmetry: 20–99V, OFF
  • Startup Delay: 1–300 seconds
  • Reset Delay: 1–600 seconds
  • Undervoltage trip delay setting: 0.1s~5.0s
  • Overvoltage trip delay setting: 0s~5s
  • Overcurrent trip delay setting: 0s~600s
Design & Monitoring: DIN rail-mounted module with a digital display, internal temperature indicator, and last-fault memory record.

For more information, please refer to the user manual in the 'Download' section or follow this link.
