Vendor: TENSE

Asymmetric / Symmetric Cyclic Flasher Timer Relay, DIN rail Mount, SPDT, NO+NC, dual power AC/DC ERV-09, TENSE

SKU: ERV-09
£19.00
£19.00
50 in stock
  • Description
  • Download
  • Payment methods
  • Warranty

DIN rail mount asymmetric and symmetric Cyclic flasher Timer Relay, SPDT, NO+NC, dual power AC/DC, TENSE (Made in Turkey)

Tense ERV-09 is a double adjustable and multifunctional asymmetric / symmetric flasher relay (cyclic timer relay) manufactured by Tense Electronics. It is designed for applications requiring alternating "On" and "Off" time control, such as industrial equipment, ventilation, or lighting systems such as:

  • Regular room or pool ventilation;
  • Advertizing with light or turning parts;
  • Signalling / alarm equipment;
  • Cyclic dehumidification;
  • Signalling / alarm equipment;

Key features:

  • Operating Range: Both "On" (Working) and "Off" (Waiting) times are independently adjustable from 1 second to 100 hours.
  • Adjustable Stages: Includes six selectable time ranges: 10s, 100s, 10m, 100m, 10h, and 100h.
  • Operating Voltage: Dual supply options are typically available—220V AC (A1-A2) and 24V AC/DC (A3-A2).
  • Output: 1 Relay (Changeover contact), rated at 5A / 250V AC.
  • Mounting: DIN rail .

Technical Specification:

  • Power supply: 24V AC/DC (A2-A3), 150V...260V AC (A1-A2);
  • Frequency: 50/60 Hz;
  • Timer settings: 1s ...100 h;
  • Power consumption: <4VA;
  • Operating temperature: -20C...+55C ;
  • Mounting: 35mm DIN.

Online card / PayPal payment - after completing the order, you will be redirected to the payment gateway, payment confirmation will be sent to your email.

Bank deposit- you will transfers money from you bank account into our bank account to complete your purchase. You will receive an invoice to your email no later than the next working day.

We warrant that on delivery, and for a period of 12 months from the date of delivery any products which are goods shall:

  • conform in all material respects with their description and any relevant specification;
  • be free from material defects in design, material and workmanship;
  • be of satisfactory quality
  • In the event of any goods being materially defective, we will replace or repair the product or refund the purchase price.

These warranties shall not apply to any defect which arises from improper use, failure to follow the product instructions, or any repair or modification made without our consent.
