Vendor: TENSE

Dual Display Panel Mount PID Temperature Controller, 2 Relay Outputs, -100°C ... +1750°C, resolution / step 0.1ºC

SKU: DT-48Y
£41.10
£41.10
Low stock: 10 left
Height x Width: 48 mm x 48 mm (1/16 DIN)
  • Description
  • Download
  • Payment methods
  • Warranty

Simple to setup and easy to use dual display panel mount PID temperature controller with alarm function, 2 output relays, -100°C ... +1750°C, resolution / step 0.1ºC, TENSE (Turkey)

New series of TENSE microprocessor PID Temperature Controllers wit dual display for set and process value (SV+PV), Alarm output, wide temperature control range and universal input for temperature probes, two output relays (NO+NC) - provides customers with powerful instrument for cost-effective and highly versatile temperature control in such applications as:

  • OEM
  • Food & Beverage
  • Plastics Extrusion
  • Furnaces & Ovens
  • Catering Equipment
  • Incubators
  • R&D and lab equipment
  • hot plates
  • HVAC applications



Features

  • Microprocessor Based, PID Temperature Controller
  • Auto-tuning for PID Parameters
  • Sensor Type: T/C (J,K,T,S,R), Pt100
  • Selectable Control Type: P, PI, PD, PID or ON-OFF
  • Automatic “Overshoot” Elimination in PID Mode
  • Anti-windup
  • Upper and Lower Limit for SET and ALARM Settings
  • Selectable Relative, Absolute or Band Alarm
  • ON-delay for OUT in Cooling Mode
  • Displays SET and PROCESS Values
  • Cold-junction Compensation for T/C
  • Line Compensation for Pt100
  • Excellent Linearity with °C/mV and °C/Ohm Look-up Tables
  • Input “Offset” Feature
  • Password Protection
  • High Accuracy
  • EEPROM Memory to Store Settings
  • Optional SSR Output
  • Easy Connection with Plug-in Connectors



You can order our temperature sensors - type J Fe-Const thermocouples (metric 6/8) with a temperature measurement scale: -100 °C - +600 °C by following this link

Online card / PayPal payment - after completing the order, you will be redirected to the payment gateway, payment confirmation will be sent to your email.

Bank deposit- you will transfers money from you bank account into our bank account to complete your purchase. You will receive an invoice to your email no later than the next working day.

We warrant that on delivery, and for a period of 12 months from the date of delivery any products which are goods shall:

  • conform in all material respects with their description and any relevant specification;
  • be free from material defects in design, material and workmanship;
  • be of satisfactory quality
  • In the event of any goods being materially defective, we will replace or repair the product or refund the purchase price.

These warranties shall not apply to any defect which arises from improper use, failure to follow the product instructions, or any repair or modification made without our consent.
