Vendor: TENSE

Multi-function Timer Relay DIN Rail Mount, 10 functions, 0.1 s - 30 h 12V-240V AC/DC, NO+NC SPDT, ERX-30, TENSE

SKU: ERX-30
£24.00
£24.00
70 in stock
  • Description
  • Download
  • Payment methods
  • Warranty

Multi-function Timer Relay DIN Rail Mount, 10 functions, 0.1 s - 30 h 12V-240V AC/DC, 1 C/O SPDT, ERX-30, TENSE (Made in Turkey)

TENSE ERX-30 multi-function timer relay is designed for time-depended control.

High accuracy, compact form, universal supply voltage range is ideal for any industrial process control panels:

  • Food and beverages
  • Mining and Raw material handling
  • Chemical industry;
  • Textile;
  • OEMs



Main features

  • 10 time functions including ON Delay, OFF Delay, Cyclic, Impulse, Latching, One-Shot, Symmetrical Off/On flasher;
  • Time setting range: from 0,1 s up to 30 hours (via 10 selectable time ranges);
  • Universal supply voltage range 12V-24V AC or DC;
  • 4 LED status indicators;
  • Slim design - only 17,8mm width;
  • Standard 35mm DIN-rail mount



Technical Specification:

  • Power supply: 12V-240V AC/DC;
  • Frequency: 50/60 Hz;
  • Timer settings: 0,1s.....30h;
  • Power consumption: <4VA;
  • Operating temperature: -20C...+55C ;
  • Mounting: 35mm DIN.

Download on

User manual

Online card / PayPal payment - after completing the order, you will be redirected to the payment gateway, payment confirmation will be sent to your email.

Bank deposit- you will transfers money from you bank account into our bank account to complete your purchase. You will receive an invoice to your email no later than the next working day.

We warrant that on delivery, and for a period of 12 months from the date of delivery any products which are goods shall:

  • conform in all material respects with their description and any relevant specification;
  • be free from material defects in design, material and workmanship;
  • be of satisfactory quality
  • In the event of any goods being materially defective, we will replace or repair the product or refund the purchase price.

These warranties shall not apply to any defect which arises from improper use, failure to follow the product instructions, or any repair or modification made without our consent.
