Vendor: ONKA

ONKA fuse terminal 2.5mm2 spring clamp with fuse holder (without fuse) grey, BR-1020223

SKU: BR-1020223

Price including VAT:

£2.58
£2.58
300 in stock
  • Description
  • Payment methods
  • Warranty

Spring clamp (Push-in) connection type fuse with fuse holder (fuse is not included) 2-wires, grey, ONKA, made in Turkey

Terminal designed to protect low current AC or DC circuits. You could use 5x20 mm fuse with a current setting up to 6.3 A. The fuse cartridge is not included and has to be ordered separately.



Technical parameters

Cross section of the connected single wire up to: 2.5 mm2
Colour: grey
Insulating material of the main housing: polyamide (PA6.6)
Contact/bridge material: stainless steel/copper
Connection position: Top / top
Cable strip length: 9mm
Electrical connection type: screw clamp
Rated voltage: 750V
Rated current: 6.3A
Operating temperature range from: -40°C
Operating temperature range up to: 140°C
Mounting method: DIN 35 mm mounting rail
Norm: EN-60947-7-1
